Process, Material Selection, And Application Areas of Multi-layer Printed Circuit Boards

Views: 0     Author: Site Editor     Publish Time: 2025-06-23      Origin: Site

Inquire

facebook sharing button
twitter sharing button
line sharing button
wechat sharing button
linkedin sharing button
pinterest sharing button
whatsapp sharing button
sharethis sharing button

1、 Core process technology

1. Precision lamination and interconnection process

The core of multi-layer PCB lies in interlayer alignment and bonding, and key technologies include:

Laminated laminate

Material stacking: The inner core board (copper-clad substrate) and the semi cured sheet (PP sheet) are alternately stacked and pressed under high temperature (180 ℃± 5 ℃) and high pressure (300-400 psi) in a vacuum environment.

Positioning system: Front positioning (PIN-LAM, accuracy ≤ 75 μ m) is used for high-density boards; MASS-LAM has higher efficiency and lower cost.

Micro hole processing

Laser drilling: CO ₂/UV laser drilling blind buried holes (aperture 0.1-0.2mm), with a depth to diameter ratio of 8:1, supporting high-density interconnection of more than 20 layers.

Resin plug hole: The through-hole is filled with epoxy resin to prevent welding short circuits, which is a mandatory requirement in the automotive electronics field.

Surface Treatment

ENIG immersion gold: high solder joint strength (45MPa), corrosion-resistant, used for BGA packaging;

OSP lead-free processing: environmentally friendly and low-cost, suitable for consumer electronics.

2. Breakthrough in advanced technology

HDI (High Density Interconnect) technology

Using arbitrary layer micropores (pore size 50 μ m) and laser direct imaging (LDI), the line width/spacing reaches 40 μ m, reducing the volume by 50% compared to traditional PCBs.

Rigid flexible combination design

The flexible zone (PI substrate) and rigid zone (FR-4) are mixed and compressed to adapt to dynamic structures such as foldable screens and mobile phone shafts.

Thin core layer processing

0.15mm ultra-thin core board replaces POFV process to solve the problem of resin plug hole deformation in ultra-thin boards (0.3mm).

2、 Material selection and performance comparison

The performance of multi-layer PCBs is highly dependent on the substrate, and the mainstream materials and applicable scenarios are as follows:

Material type, characteristics, advantages, limitations, applicable scenarios

FR-4 epoxy resin has low cost (¥ 20-50/㎡), flame retardancy (UL94 V-0), high mechanical strength (bending resistance>400MPa), and high high-frequency loss (Df> 0.02@1GHz )Consumer electronics motherboards and industrial control devices 68

High Tg epoxy resin has excellent heat resistance (Tg ≥ 170 ℃) and is suitable for lead-free soldering (peak 250 ℃). The cost is 30% higher than standard FR-4 for automotive ECU and high-power power module 6

Polyimide (PI) is flexible and bendable, resistant to high temperatures (300 ℃), highly resistant to radiation and moisture absorption (>2%), and expensive (¥ 80-120/㎡) for aerospace sensors and foldable screen smartphones

PTFE (Teflon) has extremely low high-frequency loss (Df< 0.002@10GHz )Stable dielectric constant (Dk ≈ 2.1), difficult processing (requires plasma activation), extremely high cost (¥ 200-300/㎡), 5G base station antenna, millimeter wave radar 93

Ceramic substrate (LTCC) has high temperature resistance (>800 ℃), high thermal conductivity (24-170 W/mK), high brittleness, difficult to repair military communication, and high-power lasers

The golden rule for selecting materials:

First choice for cost-effectiveness: FR-4 (accounting for 70% of global usage);

High frequency and high speed: PTFE or modified FR-4 (mixed pressure design reduces costs by 30%);

Extreme environment: PI or ceramic substrate.

3、 Application Fields and Typical Cases

1. Communication and computing (accounting for 45%)

5G base station: mixed voltage PTFE+FR-4, 12 layer board supports 28GHz RF, impedance control ± 3%.

AI server: 20 layer HDI board, embedded resistance and capacitance technology integrated GPU/CPU, signal rate 112G PAM4.

2. Automotive electronics (accounting for 25%)

Autonomous driving domain controller: 8-layer aluminum substrate+2oz thick copper, thermal conductivity of 4.0W/mK, vibration resistance of 20G.

800V battery management system: 6-layer ceramic filled FR-4, withstand voltage of 3kV, insulation resistance>100G Ω.

3. Consumer electronics (accounting for 20%)

Smartphone: 10 layers of arbitrary HDI (thickness ≤ 1.0mm), supporting dynamic folding screen structure.

AR/VR equipment: 6-layer rigid flex bonding plate, bending radius 3mm, transmission 4K@120Hz Video.

4. Special fields

Medical imaging: Low loss modified FR-4 (Df<0.02) ensures MRI signal accuracy.

Aerospace: Polyimide multilayer board, resistant to cosmic rays>100krad, used for satellite communication.

 4、 Process Challenges and Response Strategies

Technological progress in challenge solutions

Ultra thin board warpage symmetrical laminated design+low CTE material (CTE<10ppm/℃) laser real-time compensation pressing parameters

High frequency material processing is difficult, PTFE surface plasma activation → improving copper foil adhesion. Domestic hydrocarbon resin (Dk=3.0) replaces imports

Uneven pulse reverse electroplating and oscillation filling technology for micro hole electroplating, with a depth to diameter ratio of 12:1, breakthrough in micro hole capability

5、 Future Trends and Selection Suggestions

Technological Evolution Direction

High frequency: 6G promotes the research and development of nano ceramic substrates with Dk<3.0;

Miniaturization: laser micro hole aperture reduced to 30 μ m, 42 layer board thickness ≤ 0.8mm;

Green manufacturing: Halogen free FR-4 penetration rate>80% (driven by EU RoHS)
