Advantages of 22F Material Circuit Board
Outstanding high-frequency performance
22F material has a lower dielectric constant dielectric loss, suitable for high-frequency and high-speed signal transmission, which can effectively reduce signal delay and interference, and enhance circuit stability17.
Cost and efficiency
As a single-sided PCB material, the manufacturing process of 22F is simplified (such as no need for multi-layer lamination), reducing production costs suitable for large-scale rapid production18.
Withstand high temperature and mechanical strength
22F base material usually uses CEM-1 class composite epoxy resin, which has good heat resistance (such as 288℃ heat shock test passed) and mechanical strength, suitable for high-temperature environments such as automotive electronics510
Environmental friendliness
Modern manufacturing processes (such as die-cutting hot pressing) reduce the use of etching solution, in line with the trend of green15.
Lightweight and thin design
The single-sided structure makes the circuit board lighter and thinner, suitable for portable devices (such as mobile phones, tablets)10.
Second, the types of circuit boards that can be manufactured with 22F material
Single-sided PCB
The main type, suitable for simple design, such as home appliance control board, LED lighting circuit, etc. 810.
High-frequency signal board
Using its low loss characteristics, it is for high-frequency scenarios such as wireless communication devices, radar systems, etc. 17.
Power circuit board
Combined with aluminum substrate process, improve heat dissipation, used for power modules and automotive electronics510.
Flexible single panel (optional)
Paired with flexible base material (such as PET film), it manufacture flexible circuit boards, used for wearable devices.
