Parameter | Value |
Test | Fly needle test |
Plate | FR-4 |
Minimum line spacing | 0.35mm |
Thickness of te board | 1mm |
Product type | Printed circuit board |
The core of this printed circuit board uses FR-4 material, selected specifically for its exceptional mechanical strength and consistent dielectric properties. We support extensive customization capabilities, scaling from standard 4-8 layer configurations up to highly complex, multi-layered High-Density Interconnect (HDI) and rigid-flex designs to meet stringent miniaturization demands.
It has a thickness of 1mm, ensuring structural durability while remaining thin enough for densely packed electronic enclosures. The advanced lamination process and high-grade prepreg materials guarantee a smooth, rigid finish that resists warping under thermal stress.
Minimum line spacing is 0.35mm. This precise spacing accommodates intricate routing paths essential for modern microprocessors, preventing electrical shorts and supporting the dense component placement required in advanced circuitry.
Each board undergoes a fly needle test to verify electrical continuity and isolate any potential open or short circuits. Beyond this foundational test, our comprehensive quality control integrates free Design for Manufacturability (DFM) reviews, Automated Optical Inspection (AOI), and Automated X-ray Inspection (AXI) to ensure zero-defect delivery for even the most complex internal structures.
By vertically stacking intricate routing layers, a compact 10cm² board can hold dozens of chips, allowing complex designs in limited space. This architectural advantage allows engineers to execute highly demanding logic designs within a severely restricted physical footprint, ensuring rapid data transfer rates and synchronized component interaction without compromising the overall system architecture.
The strategic incorporation of added power and ground layers reduce signal loss by 50%, which helps avoid interference. This internal shielding effectively mitigates electromagnetic interference (EMI) and crosstalk between adjacent traces, preserving the integrity of sensitive analog and digital signals in densely populated environments.
Transitioning to multilayer designs reduce crosstalk and noise, supporting stable function in 5G RF modules. By consolidating the circuitry into a single, cohesive unit, the overall board weight is significantly diminished. This streamlined approach eliminates the need for bulky wiring harnesses, making the final assembly much lighter and easier to manage during installation.
Custom multilayer boards weigh 30–50% less than stacked single-layer boards, which suits aerospace devices. This extreme compactness is particularly advantageous for wearable tech and portable diagnostic tools, where every millimeter of saved space allows for larger batteries or additional sensor integration without increasing the external dimensions of the product.
Advanced smart bands use 6–8 layers to combine sensors and processors, reducing volume by about 60%. This dense integration provides the ultra-short signal paths necessary to support high-frequency data transmission without introducing latency or signal degradation, ensuring real-time responsiveness in smart devices.
Thermal management is critical in high-power applications. For instance, an 18-layer board using RO4350B material can handle 7GHz radar signals with low signal loss. The advanced lamination techniques and thermal vias dissipate heat efficiently, offering high reliability and thermal stability perfectly suited for industrial control systems and automotive electronics operating in extreme environments.
Intelligent circuit boards are also widely used in household appliances, such as televisions, refrigerators, washing machines, etc., to achieve control and operation of household appliances. They manage complex automated cycles, regulate temperature sensors, and process user inputs from sleek touch panels, ensuring smooth, responsive, and reliable daily operation for end-users.
Circuit boards are widely used in computer hardware, including motherboards, graphics cards, sound cards, etc., to achieve connections and communication between various internal components. The rigid, durable FR-4 substrate ensures these critical components withstand the thermal cycles of heavy computational workloads, facilitating instantaneous high-bandwidth communication.
Circuit boards play a core role in communication equipment, such as mobile phones, telephones, routers, etc., used to achieve functions such as signal processing and data transmission. The minimized line spacing ensures that voice and data packets are transmitted with absolute clarity and zero interruption, acting as the central nervous system for enterprise networks.
Precision and reliability are non-negotiable, which is why our circuit boards are also used in medical equipment, such as electrocardiographs, blood pressure monitors, oximeters, etc., to achieve signal acquisition, processing, and display. They operate silently and dependably to assist healthcare professionals in critical diagnostic environments where accuracy is paramount.
We believe that through the professional services and excellent quality of Dongguan Xinrongxing Technology Co., Ltd., we will definitely bring more efficient guarantees to your business and contribute to your success. Our production workflows strictly adhere to international authoritative standards, including IPC Class 3, RoHS compliance, and ISO9001 certification. This ensures that every unit we produce meets the rigorous entry and environmental requirements of the global high-end market. Welcome to contact us anytime, let's create a better future together!
Our technical team has rich experience and can provide you with support in circuit board design, manufacturing, and maintenance. Beyond bare board fabrication, we offer a complete, one-stop PCBA assembly service. This turnkey solution covers everything from global component sourcing to precision SMT and BGA placement, culminating in full Box Build assembly, drastically reducing your supply chain management complexities.
We provide comprehensive after-sales service to ensure that customers have no worries during use. Our dedicated engineers are available for in-depth troubleshooting, performance optimization, and rapid response to any technical inquiries. We stand behind the structural integrity and electrical performance of our multilayer boards, ensuring your end products perform flawlessly in the field.
We have a comprehensive logistics delivery system to ensure that products can be delivered to customers in a timely manner. Equipped with dedicated rapid prototyping lines and high-capacity mass production facilities, we support a seamless transition from initial R&D sampling to full-scale flexible manufacturing. Whether you require standard lead times or expedited urgent deliveries, our logistics network guarantees secure and punctual arrival.
A：Our printed circuit boards are made with high-quality FR-4 material, known for its excellent insulation and mechanical strength. For specialized high-frequency applications, RO4350B material is used to ensure low signal loss and thermal stability. The tactile rigidity and smooth finish of these materials reflect our commitment to durable, long-lasting electronic foundations.
A：The minimum line spacing is 0.35mm, and the standard thickness of each board is 1mm. These specific parameters are strictly maintained to support compact, highly reliable, and performance-driven designs, ensuring every trace is perfectly isolated to prevent electrical interference.
A：Our multilayer PCBs are used in a wide range of demanding applications, including:
Household appliances (e.g., smart TVs, energy-efficient refrigerators)
Computer hardware (e.g., advanced motherboards, dedicated graphics cards)
Communication equipment (e.g., mobile phones, high-speed routers)
Medical devices (e.g., precise ECG monitors, digital pulse oximeters)
A：We offer comprehensive after-sales support, including detailed troubleshooting, proactive product maintenance, and expert technical assistance. Our dedicated support team is readily available to address any operational concerns, providing clear guidance and effective solutions to ensure the continued, uninterrupted performance of your electronic products.
A：In addition to being highly regarded within China, our products are securely exported to major international markets such as the USA, India, Germany, and Vietnam. Our secure packaging and global logistics partnerships ensure that every shipment arrives in pristine condition, ready for immediate assembly.
